Reliable Microtomes for Precision Tissue Sectioning

Experience precision, reliability, and consistent performance with Micron Instrument Industries. With a legacy of manufacturing excellence since 1966, our microtomes are designed to deliver accurate and smooth tissue sectioning for histopathology laboratories, hospitals, research institutions, medical colleges, and diagnostic centers.

Get a Free & Fast Quote

First Name *

Last Name *

Email *

Phone Number *

Tell us more about your application *

Additional questions/comments

Compare Microtome Specifications

Specification	MARM-MT	MARM-ST	MARM-AT
Microtome Type	Manual Rotary Microtome	Semi Automatic Microtome	Fully Automatic Microtome
Operation Mode	Manual	Semi-automatic with stepper motor drive	Fully automatic or manual
Section Thickness Range	0–60 µm	0.5–100 µm	0.5–100 µm
Section Thickness Settings	0–2 µm: 0.5 µm increments 2–10 µm: 1 µm increments 10–20 µm: 2 µm increments 20–60 µm: 5 µm increments	0.5–2 µm: 0.5 µm increments 2–10 µm: 1 µm increments 10–20 µm: 2 µm increments 20–50 µm: 5 µm increments 50–100 µm: 10 µm increments	0.5–2 µm: 0.5 µm increments 2–10 µm: 1 µm increments 10–20 µm: 2 µm increments 20–50 µm: 5 µm increments 50–100 µm: 10 µm increments
Trimming Thickness Range	Not specified	5–500 µm; 600 µm optional	1–600 µm
Trimming Thickness Settings	Not specified	5–10 µm 10–100 µm: 10 µm increments 100–200 µm: 20 µm increments 200–500 µm: 50 µm increments 50–100 µm: 10 µm increments	5–10 µm 10–100 µm: 10 µm increments 100–200 µm: 20 µm increments 200–500 µm: 50 µm increments 50–100 µm: 10 µm increments
Specimen Retraction	Not specified	Adjustable, 5–100 µm	Adjustable, 5–100 µm
Horizontal Specimen Stroke / Feed	28mm	28mm	28mm
Vertical Specimen Stroke	60mm	60mm	60mm
Specimen Orientation	8° along X-Y axis; 360° rotation	8° along X-Y axis; 360° rotation	8° along X-Y axis; 360° rotation
Specimen Feed Speed	Manual coarse feed wheel	1250 µm/s (click); 2000 µm/s (press and hold)	1250 µm/s (click); 2000 µm/s (press and hold)
Cutting Speed	Manual	Mode and speed controlled electronically; numeric range not specified	Mode and speed controlled electronically; numeric range not specified
Motor / Drive	Manual mechanical drive	Stepper motor drive; 0.1 µm accuracy	Stepper motor and motor drive; 0.1 µm resolution
Display / Interface	Not applicable	5-inch color TFT touch screen	5-inch color TFT touch screen
Displayed Parameters	Not applicable	Slice thickness, trimming thickness, section counter, mode and speed	Slice thickness, trimming thickness, section counter, mode, speed, stroke distance
Handwheel Locking	Lockable in any position or at highest point	Lockable in any position	Lockable in any position
Blade Carrier	Specialized disposable blade carrier; high and low profile blades	Specialized disposable blade carrier; high and low profile blades	Specialized disposable blade carrier; high and low profile blades
Specimen Clamp	Universal cassette clamp and standard specimen clamp	Universal cassette clamp and standard specimen clamp	Universal cassette clamp and standard specimen clamp
Maximum Section Size	50 × 45 mm	50 × 45 mm	50 × 45 mm
Safety Features	Finger protection guard; handwheel locking	Protection guard; handwheel locking	Alarm system, overload protection, sleep mode, emergency stop
Waste Tray	Easily removable / disassembled waste tray	Easily removable / disassembled waste tray	Easily removable / disassembled waste tray
Control Features	Optional clockwise or counterclockwise coarse feed wheel rotation	Keyboard controls for thickness, mode and speed	Keyboard control panel for trimming/section thickness, stroke and cutting speed; foot switch
Dimensions (L × W × H)	300 x 460 x 290 mm	320 × 500 × 300 mm	500 × 500 × 320 mm
Net Weight	30 kg	30 kg	32 kg
Power Supply	Not applicable / manual	220 V / 50 Hz	220 V / 50 Hz

Precision You Can Trust

Trusted Histopathology Equipment Since 1966

With over six decades of manufacturing expertise, Micron Instrument Industries provides reliable microscopes and histopathology laboratory equipment for educational institutions, hospitals, diagnostic laboratories, research organizations, and government laboratories across India and international markets.

Our microtomes are engineered for precise, smooth, and consistent tissue sectioning, helping laboratory professionals achieve dependable results across routine histopathology, clinical, research, and educational applications.
